SIM Card Forensics: Extracting Secrets, Cloning Risks, and Building Your Defense

Disclaimer: This article is for educational purposes only. The techniques described may be illegal in certain jurisdictions. Use only with proper authorization.

TL;DR

• I learned how to pull a SIM’s data, contacts, and encryption keys using a Raspberry Pi and a smart-card reader.
• I discovered that old SIMs can be cloned in under an hour, while modern chips use rate limiting and tamper-resistant design.
• I built a small test rig that extracts the ICCID, ADN, FDN, KC, and SST files, and I shared the steps to interpret them.
• I highlighted the pitfalls of using SS7 and IMSI catchers, and I outlined legal boundaries.
• I added a handy comparison table of tools and a glossary to keep the jargon in check.

Why This Matters

SIM cards are the heart of any mobile device, yet they are often treated like generic “smart cards” with little thought about the data they hold. Security researchers, forensic analysts, and telecom engineers have faced pain points such as:

• Hard to pull data from encrypted SIMs without the correct keys.
• The need to switch between nano, micro, and standard sizes with no single adapter.
• Rate-limiting chips that throttle challenge-response pairs, making brute-force attacks time-consuming.
• A file system that is logical, not intuitive—no menu, just a hierarchy of folders.
• The threat that new 2025 vulnerabilities could slip past current defenses. Understanding the SIM forensics workflow helps you stay ahead of attackers who will try to clone your device’s identity and track you in real time.

Core Concepts

A SIM card’s internal structure is defined in 3GPP TS 31.102 SIM card — 3GPP TS 31.102 (2023). Think of it as a miniature filing cabinet:

• The KC file holds the secret key that encrypts all over-the-air traffic. It is regenerated on each authentication, so capturing it in real time is the key to hijacking calls and texts.
• The KI (Key Identifier) is the master key that can derive the KC. Modern SIMs store the KI in a tamper-resistant chip that throttles challenge-response attempts (rate limiting).

Table: Tool Comparison

How to Apply It

Below is a hands-on, step-by-step recipe that I followed in my lab. If you have a Raspberry Pi, a smart-card reader, and a blank programmable SIM, you’re ready.

1. Gather the Gear

2. Set Up the Pi

sudo apt update
sudo apt install python3-pip
pip3 install pyscard

The pyscard library lets you talk to the reader over USB.

3. Insert the Blank SIM and Reader

Plug the reader into the Pi’s USB port, then insert the programmable SIM into the reader via the adapter.

4. Read the Master File (MF)

from smartcard.System import readers
r = readers()[0]
connection = r.createConnection()
connection.connect()
# SELECT MF
connection.transmit([0x00, 0xA4, 0x00, 0x00, 0x02, 0x3F, 0x00])

If the response is 90 00, the card is healthy. Read the ICCID:

# READ BINARY of ICCID file (AID: 2F 2F)

5. Dump GSM Folder

# SELECT GSM folder
connection.transmit([0x00, 0xA4, 0x04, 0x00, 0x02, 0x7F, 0x20])
# READ BINARY of KC file

The KC is the ciphering key that encrypts the air interface. It changes on every authentication, so you need a real-time capture.

6. Capture the KI via MagicSim (Optional)

If you have a MagicSim device, connect it to the reader and run the tool. It will send thousands to millions of challenge-response pairs to reverse engineer the KI MagicSim — SIM Cloning Tool (2020). The tool is powerful against weak, early-2000s SIMs; modern chips block you after ~50 attempts.

7. Pull User Data (ADN, FDN, SST)

Use the same SELECT commands to access the Telecom folder and export the files.

• ADN gives you the full contact list.
• FDN lists fixed dialer numbers (useful for security checks).
• SST tells you which services (SMS, GPRS, etc.) are allowed.

8. Interpret the Results

9. Legal & Ethical Boundaries

• Use only on SIMs you own or have explicit permission to analyze.
• Cloning a SIM to hijack calls/texts is illegal in most jurisdictions.
• SS7 key capture is a high-risk activity that can trigger law-enforcement investigation.
• Disclose any findings responsibly to the carrier or security community.

Pitfalls & Edge Cases

Quick FAQ

1. How can modern SIMs with rate limiting be cracked to obtain the KI? Modern chips enforce a strict challenge-response quota. Attackers often use SS7 MITM or StingRay to intercept the authentication exchange in real time, capturing the KI before the rate limit is triggered.

2. What specific rate limiting mechanisms exist in modern SIMs? The chip counts the number of AUTHENTICATE APDUs sent within a time window. Once the threshold is reached, it returns an error or refuses further authentication until the window resets.

3. How does the SS7 vulnerability allow key capture? SS7 can be used to send spoofed authentication requests to the mobile network. The network responds with the challenge and key material, which can be captured and replayed.

4. What are the legal implications of using IMSI catchers/StingRays? In many countries, operating an IMSI catcher without a court order is illegal and can lead to civil or criminal penalties.

5. How effective are ACMmax protections against prepaid call meter tampering? ACMmax limits the accumulated call time stored on the SIM. If tampered, the network will refuse service once the limit is reached, preventing over-charging.

6. Can SIM modules be used for legitimate purposes besides hacking? Absolutely. SIM modules enable IoT devices to connect to cellular networks without a smartphone, useful for remote monitoring, fleet tracking, or home automation.

7. What new vulnerabilities exist in 2025 that are not covered in the video? Preliminary reports point to encrypted storage of KI on new UICC chips and dynamic rate limiting that adjusts thresholds per subscriber. Stay tuned to 3GPP release 19 and vendor security advisories.

Conclusion

You now know how to pull data from a SIM, understand the risks of cloning, and what to watch out for in modern devices. If you’re a forensic analyst or a hobbyist, equip yourself with the right hardware and stay on top of the latest 3GPP specs. If you’re a carrier, consider tightening your SS7 controls and monitoring for unusual authentication patterns. And always remember: knowledge is power, but misuse is crime.

References

• SIM card — 3GPP TS 31.102 (2023)
• SIM card — 3GPP TS 31.101 (2023)
• RFC 2935 — GSM Mobile Station Authentication (2001)
• MagicSim — SIM Cloning Tool (2020)

Glossary
