Turn Android SMS JSON Backup into Readable Chat Archives

TL;DR

• I pull an uncompressed Android SMS backup with adb and keep it encrypted with AES-256.
• I unpack the backup with Android Backup Extractor, unzip the Zlib files, and get five JSONs.
• I use a custom Bash viewer (smsviewer.sh) that leverages FZF and jq to browse conversations in the terminal.
• I can export the cleaned chat to plain-text file.

Why this matters

When I’m chasing a lead or verifying an alibi, I have to sift through millions of SMS messages. Raw backup.ab files are a wall of binary and JSON that even the most patient analyst can’t read. They’re encrypted, split, and compressed. If you can turn that chaos into a clean, scroll-able archive, you save hours of manual work and reduce the chance of overlooking a critical message.

Core concepts

The process is a chain of four transformations:

I call the final product a human-readable chat archive. It’s a simple list of messages, sorted by timestamp, with the contact name, direction, and a color that tells you whether it was sent or received.

How to apply it

I broke the workflow into three phases: setup, extraction, and viewing.

1. Set up the environment

# 1. Update the package list
sudo apt update

# 2. Install the command-line fuzzy finder
sudo apt install -y fzf          # [junegunn/fzf — FZF (2025)]

# 3. Install jq for JSON processing
sudo apt install -y jq            # [stedolan/jq — jq (2025)]

# 4. Verify Java is present (required by ABE)
java --version                     # [OpenJDK — Java Runtime Environment (2025)]

# 5. Grab the latest Android Backup Extractor JAR
wget https://github.com/nelenkov/android-backup-extractor/releases/download/abe-5.0.0/AndroidBackupExtractor.jar

If you’re on a fresh Kali image, Java is usually pre-installed, but I always double-check.

2. Pull an encrypted, uncompressed backup

# List the backup-able packages to make sure the SMS provider is available
adb shell pm list packages | grep com.android.providers.telephony

# Pull the backup. The --no-compress flag keeps the file size small.
adb backup -f backup.ab --no-compress com.android.providers.telephony

During the backup you’ll see a confirmation prompt on the phone. If you want the backup to stay encrypted, set a password. The backup will be an AES-256 blob – the file header says it’s Android backup version 5 – and will look like gibberish:

backup.ab
└─ 0x00000000: 0x78 0x9c 0x5d 0x7a 0x5e 0x... (encrypted)

3. Unpack the backup

# ABE requires Java, so we run it with the JAR we downloaded
java -jar AndroidBackupExtractor.jar unpack backup.ab backup.tar

ABE will ask for the password you set earlier. After a few seconds you’ll have backup.tar, which contains:

apps/com.android.providers.telephony/_manifest
apps/com.android.providers.telephony/d_f/000000_sms_backup
apps/com.android.providers.telephony/d_f/000001_sms_backup
...

The _backup files are still zlib-compressed. You need to decompress them.

4. Decompress with Python 3

# The repo ships a small helper script; just run it
chmod +x decompress.sh
./decompress.sh

decompress.sh pulls zlib from Python 3 and expands each file into decompressed/000000.json, decompressed/000001.json, …, decompressed/000004.json. The JSON structure looks like:

{
  "thread_id": 123456,
  "timestamp": 1678923456000,
  "address": "+15551234567",
  "body": "Hey, are you coming?",
  "type": 1
}

All timestamps are in milliseconds since the epoch. To read them as normal dates, you can let smsviewer.sh do the math.

5. View the archive in the terminal

chmod +x smsviewer.sh
./smsviewer.sh

The script boots up FZF, shows you a list of unique contacts, and lets you pick one. Once a contact is selected, the rest of the script:

• Joins all JSON files belonging to that thread.
• Sorts by timestamp (ascending).
• Converts the epoch milliseconds to human-readable UTC (YYYY-MM-DD HH:MM).
• Colors messages: blue for sent, green for received.
• Paginates with less -R.

The output feels like a normal chat app:

[2023-03-14 09:12]  +15551234567   : Hey, are you coming?
[2023-03-14 09:13]  +15551234567   : I’m on the way!

When you’re done, press Ctrl-X to export the conversation to a plain-text file (conversation.txt). The file is ready for forensic report or for importing into a spreadsheet.

Pitfalls & edge cases

I’ve seen people get stuck on the “cannot find java” error. That usually means the $JAVA_HOME variable isn’t set, or the JRE is older than Java 11 – ABE requires Java 11 or newer.

Quick FAQ

Conclusion

The key takeaway: if you’re a forensic analyst, penetration tester, or even an Android developer who wants to audit their own SMS history, you can convert a raw Android backup into a clean, color-coded chat archive in under an hour. The workflow hinges on four main tools—ADB, Android Backup Extractor, Python 3/Zlib, and a custom Bash viewer. Keep the tools up to date, secure your backup password, and you’ll have a reproducible pipeline that turns binary mess into a readable conversation you can export and analyze.

Next steps for me:

1. Add a time-zone flag to smsviewer.sh so the timestamps match my local clock.
2. Write a quick wrapper that pulls, extracts, and opens the viewer in one go.
3. Share a Docker image that bundles all dependencies so the process is repeatable on any Linux distro.

If you’re new to Kali Linux, start by installing the packages above and experiment with a small backup. Once you’re comfortable, try it on a real case and see how much time you save.

References

• [junegunn/fzf — FZF (2025)]
• [stedolan/jq — jq (2025)]
• [OpenJDK — Java Runtime Environment (2025)]
• [Android Developers — ADB (2025)]
• [nelenkov/android-backup-extractor — Android Backup Extractor (2025)]
• [DouglasFreshHabian/Backup2Chat — Backup2Chat (2026)]
• [Zlib — Zlib Library (2025)]
• [Python.org — Python 3 (2025)]
